Wafer Duo Check Valve EPDM and NBR Seats
Regular price
$4,018.81 MXN
Pickup availability could not be loaded
Device designed to control the unidirectional flow of fluids in industrial systems. Its compact and lightweight design allows for easy installation between pipe flanges. The valve is equipped with two retaining discs which open automatically when the flow is in the permitted direction and close to prevent flow in the opposite direction. This ensures the protection of the system and prevents unwanted return of fluids.
The wafer-type Duo Check valve is ideal for applications where a safe and reliable flow control in confined spaces.
Characteristics:
- Wafer Type Mount
- Cast Iron Body
- Double Plate Disc SS 304
- SS 304 Spring
- NBR-EPDM seat
- SS 416 stem
- ANSI 150 flanges
- Working Pressure: 232 PSI PN16
- Working Temperature: -20ºC to 80ºC
